MI6-MBN6 MBUX

Camera interface for easy retrofitting of AXION cameras (rear view camera, side camera, front camera, etc.) in Mercedes Sprinter W907/W910 from 2018 with 7" and 10" MBUX systems.

• Video Interface for Mercedes Sprinter W907/W910 from 2018 7" and 10" MBUX systems
• 4 video inputs (2x AXION DIN rear view camera/front camera, 2x Cinch for additional cameras e.g. side camera left/right)
• Own OnScreen menu for easy configuration
• Automatic switching to all camera inputs, taking into account different switching logics and vehicle speed from all operating modes
• Dynamic and adjustable parking assistance lines for perfect personalization
• Integration of the original PDC graphic into the camera image
• 2 independent switching outputs (+12V max. 1A)
• PIP (picture in picture) modes for combining aftermarket cameras with the possibly existing factory camera
• Simultaneous display of parking distance graphics and dynamic parking auxiliary lines possible
• Blinker controlled function of the side cameras possible
• Compatible with all movements. Video applications
• USB update port for software updates (also possible by the end user)

Available in 2 Versions:
MI6-MBN6 MBUX for vehicles with 7" or 10" MBUX System with Navigation (26pin connector)
MI6-MBN6_31 for vehicles with 7" MBUX System w/o NAVIGATION (31pin connector)
