7inch LED Monitor for camera applications

CRV 7103M

7" (17.8 cm) AHD reversing monitor with 3 camera inputs, IP64 splash-proof.
Easy to install and connect (Plug & Play) - Suitable for 12 V & 24 V use

request product find a merchant

  • Professional 7-inch AHD monitor with 3 inputs for demanding applications. IP64 splash-proof design.

    • 7" (17.8 cm) rear monitor with 3 inputs
    • Supports AHD (up to 1080P & CVBS (PAL/NTSC)
    • Easy to install and connect (Plug & Play)
    • Suitable for 12 V & 24 V use
    • Operating menu in 9 languages
    • 3 camera inputs (AXION MiniDIN) & independent switching inputs (trigger)
    • Display modes: Split/PIP/Mirror/Normal
    • Switchable guide lines
    • Integrated loudspeaker
    • IP64 splash-proof
    • Incl. stand & attachable sun visor
  • Monitor7 inch
    Resolution1024 x (RGB) x 600 pixels
    Brightness500 cd/m2
    Visual angler/l 75°, u/d 70/75°
    Mirror-Functionyes (normal/mirror)
    Video-SystemHD (1080p/720p), CVBS PAL/NTSC (auto)
    Day/Night sensoryes, senosor
    Built-in speakersyes
    Video-Input3x AXION 4p MiniDIN
    Trigger3
    Power supply10-32 Vdc
    Operating temperature range-20 °C ~ + 70 °C
    Storage temperature range-30 °C ~ + 80 °C
    Guide-Linesyes (selectable)
    OSD (User-Manuel)9 languages
    Power-On modeyes
    Protection classIP64
    Dimensons (WxHxD)181x122x24 mm
    Weightapprox. 450g
    CertificationCE, ECE-R10
    • CRV 7103M Monitor
    • Connection cable set
    • Sun visor (clip-on)
    • Operating instructions
  • Download
Technical changes and errors excepted.
