7" LCD-TFT AHD monitor for camera systems

CRV 7105M HD

7" (17.8 cm) AHD reversing monitor with 2 camera inputs.
Easy to install and connect (plug & play) - Suitable for 12 V & 24 V use

request product find a merchant
    • high-resolution 7“ (17,8 cm) AHD rear view monitor with 2 camera inputs
    • Easy to install and stock (plug & play)
    • For 12 V & 24 V application
    • 7 languages OSD
    • 2 individual trigger wires
    • Guide-lines engageable
    • Buttons dimmable
    • Power on at voltage
    • built-in speakers
    • Priority adjustable
    • Incl. monitor stand
  • Monitor7 inch
    Resolution1024 x (RGB) x 600 pixels
    Brightness500 cd/m2
    Visual angler/l 75°, u/d 70/75°
    Mirror-Functionyes (normal/mirror)
    Video-SystemAHD (1080p/720p), CVBS PAL/NTSC (auto)
    Day/Night sensoryes, senosor
    Built-in speakersyes
    Video-Input2x AXION 4p MiniDIN
    Trigger3
    Power supply10-32 Vdc
    Operating temperature range-20 °C ~ + 70 °C
    Storage temperature range-30 °C ~ + 80 °C
    Guide-Linesyes (selectable)
    OSD (User-Manuel)7 languages
    Power-On modeyes
    Protection classIP54
    Dimensons (WxHxD)200x115x29 mm
    Weightapprox. 400g
    CertificationCE, ECE-R10
    • CRV 7105M - Monitor
    • Monitor stand
    • Cable kit
    • Manual
  • Download
Technical changes and errors excepted.
